UL4413 XLPE Insulated Flat Ribbon Wire

Share to:
    Payment Type: L/C,T/T,Paypal,Western Union
    Incoterm: FOB,CFR,CIF,FCA,CPT
    Min. Order: 3050 Meter
    Delivery Time: 10 Days

Basic Info

Model No.: UL4413

Type: Insulated

Conductor Type: Stranded

Conductor Material: Copper

Insulation Material: XLPE

Material Shape: Flat Wire

Range of Application: LSOH

Certification: RoHS, UL, CE, ISO9001

Additional Info

Packaging: Coil, Spool, Carton

Productivity: 50km per week

Brand: Feyvan

Transportation: Ocean,Air

Place of Origin: Jiangsu, China

Certificate: ISO9001, ISO14001

HS Code: 8544492900

Port: Shanghai,Taizhou,Guangzhou

Product Description

The UL style 4413 halogen free flex flat ribbon Sensor Cable used for internal wiring of electronic equipments especially variety of sensors. It is the XLPE insulated with stranded tinned copper wire in compliance with RoHS standard. This flat ribbon wire assemble with 2-6 conductors has the features of small bending radius, high flexibility which can help you minimize waste of space. The form of flat ribbon cable with a web between conductors, may be used same or mixed AWG sizes.


2 Cores Xlpe Flat Cable


Technical Date:

- Rated temperature: 150

- Rated voltage: 300V

- Reference standard: UL subject 758, UL1581

- Conductor: 32AWG-16AWG, tinned or bare, stranded or solid copper (2cores to 6cores)

- Insulation: XLPE with multiple color option

- Uniform insulation thickness to ensure easy stripping and cutting

- Passed UL VW-1, cUL FT1 and JQA F-mark flame test



Conductor Insulation

Cores AWG NO/mm Diameter
mm
mm mm Maximum
Resistance at 20℃
Ω/km
2 32 7/0.080 0.24 0.38 1.00*2.10 542
2 30 7/0.100 0.30 0.38 1.10*2.30 381
2 28 7/0.127 0.38 0.38 1.20*2.50 239
2 26 7/0.160 0.48 0.38 1.30*4.30 150
2 24 11/0.160 0.61 0.38 1.40*2.90 94.2
2 22 17/0.160 0.76 0.38 1.60*3.30 59.4
2 20 21/0.178 0.94 0.38 1.80*3.70 36.7

Package options:

Package

Looking for ideal UL Style CSA 150 Deg C Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the UL XLPE Halogen Free Flat Cable are quality guaranteed. We are China Origin Factory of UL 4413 Electric Flat Ribbon Cable. If you have any question, please feel free to contact us.

Product Categories : Electronic Wire > Sensor Wire
